12 23/03 – 6795769_04
1 USER INTERFACE
User interface developed for wall installation. New wall-hung digital user interface, with touch keyboard, suitable to manage fancoils of all types. It is characterised for its
captivating design and thickness of only 11 mm. This interface covers a 503 recess box. The main features are:
— LCD display
— Possibility of managing fancoils with inverter technology. In this case, fan speed can be varied, in manual functioning mode, according to a scale of 20 positions viewable
via graduated bars
— Alarms display
— Displaying the set, the season and the environment temperature read
1 ON/OFF button
2 Mode change and conrm data button
3 Data increase key
4 Data decrease key
1 42 3
