B. Remote Screen (cont)
Edit Return
Co nfig
REMOTE
Config Port: USB
Port Currently Act ive: USB
41 20 29
NOTE: For screen settings to be effective, the F5 “Config” Key should be pressed whenever the
screen is changed.
SCREEN FEATURE FUNCTION
Config Port Used to select the remote connection.
Select: ETHERNET, USB or RS-232
Port Currently Active Used to select the active remote connection.
Select: ETHERNET, USB or RS-232
F1 “Edit” / “Done” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
F2 “Return” Displays the Utilities Menu (para 2-2-5).
F5 “Config” / “Esc” Config Applies the screen parameters for the remote connection
settings.
Esc Ends the Field Edit, but does NOT save any changes to
the setting or value.
