A. DCS Decode Meter
DCS Decode
State Run
Inv 155
SCREEN FEATURE FUNCTION
State Used to enable meter operation.
Select: Run or Stop
Format Used to select the signal format.
Select: Inv (Inverted) or NonInv (Non-Inverted)
Meter Readout Used to display the signal level.
Displays “- - -“ when no signal is present.
To Next Page
