2-2-6. OTHER METERS / FUNCTIONS
When the Duplex Test Screen, Receiver Test Screen, Transmitter Test Screen or Audio Function
Generator Test Screen is displayed, there are several Meters / Functions that are available to be
placed on the Test Screen. Refer to the descriptions of the Test Screens for a list of Meters /
Functions available for use with each Test Screen.
NOTE: Refer to para 2-2-3 for a description of the SINAD Meter, Distortion Meter, AF Counter and
Audio Level Meter Screens.
AF Cntr Audio In
0. 0 Hz
Au dio Level Au dio In
0.000 V
DCS Decode
State Run
Inv 155
Distortion Audio In
0.0%
DTMF Decode
01234
01 2 34567 89
Fu nc tion Generat or
Freq Level
#1: Off 0.0 Hz 0.20 Vrms
#2: Off 0.0 Hz 0.20 Vrms
Mo d- FM Dev
16.670 kHz
RF Error
0. 0 kHz
RF Power
0.0 Watts
RSSI
0.0 dB m
SINAD Audio In
0. 0 d B
When the mini-meter is accessed on the Test Screen (F1 “Zoom” Key), the Meter is displayed in full
view for adjustment of the meter levels and parameters.
There is no Zoom function for the DCS Decode Meter, DTMF Decode Meter and Function Generator.
