2-76 Subject to Export Control, see Cover Page for details.
C. Function Generator
Fu nc tio n Ge ne rat or
Freq Level
#1: Off 0.0 Hz 0.20 Vrms
#2: Off 0.0 Hz 0.20 Vrms
SCREEN FEATURE FUNCTION
#1 (Function Generator) Used to select Function Generator #1.
Select: On or Off
Freq 0 to 20000 Hz in 0.1 Hz increments
Level 0.00 to 1.57 Vrms in 0.01 V increments
#2 (Function Generator) Used to select Function Generator #2.
Select: On or Off
Freq 0 to 20000 Hz in 0.1 Hz increments
Level 0.00 to 1.57 Vrms in 0.01 V increments
NOTE: The combined output level from both Function Generators cannot exceed 1.57 Vrms.
If the level of a selected Function Generator is set so the combined output level would
exceed 1.57 Vrms, then the output level of the unselected Function Generator is lowered
automatically.
