F. RF Power Meter Screen
RF Power
0.0 Watts
Edit Ho l d Zer
o
Re tur n
RF Power Meter
Units W
Rang e A uto
Avg Re ading 1
Limits Watts State
Lower 0.10 Off
Upper 20.00 Off
12 .8
0.0 Watts 0.1
41 20 29
(MINI-METER)
SCREEN FEATURE FUNCTION
Units Used to select the RF Power Meter units of measure.
Select: dBm or W
Range Used to select the meter range.
Select: Auto, -0-0.1W, 0-0.2W, 0-0.5W, 0-1W, 0-2W, 0-5W,
0-10W, 0-20W, 0-50W, 0-100W or 0-200W
Avg Reading Used to select the RF Power Meter Averaging.
Select: 1 to 99
This is the number of readings to average for the displayed value.
Limits - Lower Used to enable the RF Power Meter Lower Limit.
Select: 0 to 43 dBm in 0.01 dB increments
0 to 53 dBm in 0.01 dB increments (with Cable Offset)
0 to 20 W in 0.01 W increments
0 to 200 W in 0.01 W increments (with Cable Offset)
Sets the marker on the RF Power Meter Bar to the Lower Limit
selected.
Limits - Upper Used to enable the RF Power Meter Upper Limit.
Select: 0 to 43 dBm in 0.01 dB increments
0 to 53 dBm in 0.01 dB increments (with Cable Offset)
0 to 20 W in 0.01 W increments
0 to 200 W in 0.01 W increments (with Cable Offset)
Sets the marker on the RF Power Meter Bar to the Upper Limit
selected.
