2-82 Subject to Export Control, see Cover Page for details.
F. RF Power Meter Screen (cont)
SCREEN FEATURE FUNCTION
State - Lower Limit Used to display the Lower Limit Marker on the RF Power Meter
Bar.
Select: On or Off
State - Upper Limit Used to display the Upper Limit Marker on the RF Power Meter
Bar.
Select: On or Off
RF Power Meter Bar A graphical representation of the received RF Power Meter
readings.
F1 “Edit” / “Done” / “Next” Edit Highlights the selected field to be changed or changes
the field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
Next Continues with next step of Zero function.
F2 “Save” Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data dump is
stored in a time-stamped ASCII report and can be retrieved at a
later time.
F3 “Hold” / “Resume” / “Abort” Hold Freezes the screen.
Resume Restores the screen to active mode.
Abort Ends the Zero function.
F4 “Zero” Instruction pop-ups are displayed to zero the RF Power Meter.
F5 “Return” / “Esc” Return Closes the RF Power Meter Screen and returns to the
Test Screen.
Esc Ends the Field Edit, but does NOT save any changes to
the setting or value.
