2-5-2. TYPICAL VEHICLE INSTALLATION TEST (cont)
5. With the cursor on the Generator MHz Field, press the F1 “Edit” Key and use the  LEFT,
 RIGHT and Number Keys to select the desired frequency. Press the F1 “Done” Key to
save the setting.
2
4
6
8
0
1
9
7
5
3
DUP LEX TEST
Generator Of f
MHz: 40.000000
Po rt : Ant
Level: -7 0 dBm
Ext Attn dB: 0
2
4
6
8
0
1
9
7
5
3
6. With the cursor on the Generator Level Field, press the F1 “Edit” Key and use the  LEFT,
 RIGHT and Number Keys to select the desired RF level. Press the F1 “Done” Key to save
the setting.
2
4
6
8
0
1
9
7
5
3
DUP LEX TEST
Generator Of f
MHz: 40.000000
Po rt : Ant
Level: -70 dBm
Ext Attn dB: 0
2
4
6
8
0
1
9
7
5
3
7. Press the F4 “Setup” Key to display the Duplex Setup Screen.
Edit Re tur n Hold Se tup Pt t on
DUPL EX TEST
Ge ner ato r Off Receiver Mo re
MH
z: 40.00000 0 MH z: 40. 00000 0
Port: T/R Port: T/ R
Le vel: - 70 d Bm Mod: FM 10 k
Ext A ttn d B: 0 AFBW : 0.3k H P
Mo du la tor Fre q FM A nalog
Ge n 1: On 1000.0 H
z 6.25 kH z
Ge n 2: On 150.0 H
z 3.25 kH z
MI C: On
6.2 5 kH z
Ext A ud: Off Lo ad: Hig h Z
Volume: 100
Squelch: -50 dBm
Speaker: Audio In
AudOut : Audio In
