2-5-6. MEASURING REVERSE POWER (cont)
6. Press the F2 “Return” Key to display the Transmitter Test Screen.
2
4
6
8
0
1
9
7
5
3
Edit Re tur n Hol
d
Se t up
TRANSMITTER TEST
Rec ei ver M ore
MH
z: 40.000000 RSSI
Port: T/R 0.0 dBm
Mod: FM 10k
AFBW: None
Vo lu me: 100
Squel ch: -50 dBm
Speake r: Au di o In
A u d O ut : Au d i o In
Save Recall
41 20 29
7. With the cursor on the RF MHz Field, press the F1 “Edit” Key and use the  LEFT,
 RIGHT and Number Keys to match the Transmit frequency of the UUT. Press the
F1 “Done” Key to save the setting.
2
4
6
8
0
1
9
7
5
3
TRANSMITTER TEST
Recei ver More
MHz: 40.000000
Port: T/R
Mo d: FM 10 k
AFBW : Non e
2
4
6
8
0
1
9
7
5
3
8. Key the Transmitter and record the RSSI Meter reading.
9. With the cursor on the Port (RF In) Field, press the F1 “Edit” Key and use the  UP Key or
 DOWN Key to select the ANT Connector. Press the F1 “Done” Key to save the setting.
2
4
6
8
0
1
9
7
5
3
TRANSMITTER TEST
Recei ver More
MHz: 4 0.0 000 00
Port: Ant
Mo d: FM 10 k
AFBW : Non e
2
4
6
8
0
1
9
7
5
3
