3-3-2. BATTERY REPLACEMENT
DESCRIPTION
This procedure is used to replace the Battery in the 3500 / 3500A.
CAUTION
REPLACE ONLY WITH THE BATTERY SPECIFIED. DO NOT ATTEMPT TO
INSTALL A NON-RECHARGEABLE BATTERY.
WARNING
• DISPOSE OF THE LITHIUM ION BATTERY PACK ACCORDING TO LOCAL
STANDARD SAFETY PROCEDURES. DO NOT CRUSH, INCINERATE OR
DISPOSE OF THE LITHIUM ION BATTERY PACK IN NORMAL WASTE.
• DO NOT SHORT CIRCUIT OR FORCE DISCHARGE OF THE LITHIUM ION
BATTERY PACK AS THIS MIGHT CAUSE THE LITHIUM ION BATTERY
PACK TO VENT, OVERHEAT OR EXPLODE.
REMOVE
1. Fully loosen the captive screws (on each side of the bumper) in the two lower bumpers and
remove the bumpers from the 3500 / 3500A.
2. Fully loosen five captive screws holding the Battery Cover to the 3500 / 3500A and remove
the Battery Cover from the 3500 / 3500A.
