Subject to Export Control, see Cover Page for details. 4-15
4-4. OSCILLOSCOPE OPTION (35000001)
The Oscilloscope Option (35000001) adds an Oscilloscope to the testing compatibilities of the
3500 / 3500A.
The Oscilloscope provides users with the ability to perform time dependent measurement analysis.
4-4-1. OSCILLOSCOPE SCREEN
When the System Menu is displayed, press the appropriate Number Key to display the Oscilloscope
Screen.
Me ter s System Self test Uti l
1 - DUPLEX TEST
2 - RECEI VER TEST
3 - TRANSMITTER TE ST
4 - ANT-CABLE TEST
5 - AUDIO
7 - OSCILLOSCOPE
OSCILLOSCOPE
3.0 0
V >
AC
-3.00
0. 0 mS 5.0
Source: Audio In Vert: 1 V/Div Horiz: 0.5 mSec/Div
Load: 150 Vert Offset: 0 .00 V Zero
Edit Return Ho l
d
Trigger
41 20 29
The Oscilloscope Screen can also be added to the Duplex, Receiver, Transmitter and Audio Function
Generator Test Screens for easy access.
RECEIVER TEST SETUP
SINAD Meter 0
Dist ort ion Meter: 0
AF Counter 0
Audio Level 0
AF Sco pe 3
Edit Return
1
4
7
2
5
8
3
6
9
41 20 29
Edit Return Ho l
d
Setu
p
RECEIVER TEST
Generator Of f AF Scope Audio In
MH z: 40 .00 00 00
Port : T/R
Level: -70 dBm
Ext A ttn dB: 0
Modu lator Freq FM Group
Gen 1: On 1000.0 H
z 6.25 kH z
Gen 2: On 150.0 H
z 3.25 kH z
MIC: On
6.25 kH z
Ext A ud: Off Load : High Z
Vo lume : 1 00
Sq uelch : - 50 dB m
Sp eake r: A udio In
Au dOu t: A udio In
Save Recall
41 20 29
To access the Oscilloscope on the Duplex, Receiver, Transmitter and Audio Function Generator Test
Screens:
● Press the  LEFT Key or  RIGHT Key to move the on-screen cursor to the Oscilloscope
frame.
● Press the F1 “Zoom” Key to display the Oscilloscope Screen or use the  DOWN Key to
access the Oscilloscope Mini-Meter Source Field.
