4-5. TRACKING GENERATOR OPTION (35000070)
The Tracking Generator Option (35000070) adds a Tracking Generator to the testing compatibilities
of the 3500 / 3500A.
The Tracking Generator provides users with the ability to generate a carrier wave that is applied to
components or systems, which allows the output to be analyzed to evaluate the frequency response
of the device under test.
4-5-1. TRACKING GENERATOR SCREEN
When the System Menu is displayed, press the appropriate Number Key to display the Tracking
Generator Screen.
Me ter s System Self test
Uti l
1 - DUPLEX TEST
2 - RECEI VER TEST
3 - TRANSMITTER TE ST
4 - ANT-CABLE TEST
5 - AUDIO
8 - TRACK G EN
TRACKING GENERATOR
10
dB
-1 10
491.0 MHz 511.0
Gen Lvl: -5 dBm Type: Live RF in: ANT
Ref Lvl: 10 Pre amp: Off Scale: 20 Set Ref Mode
Edit
Return
Ho ld
Co ntr ol
41 20 29
To Next Page
