4-24 Subject to Export Control, see Cover Page for details.
4-5-2. TRACKING GENERATOR SCREEN FEATURES AND FUNCTIONS
TRACKING GENERATO
10
dB
-110
491.0 MHz 511.0
Gen Lvl: -5 dBm Type: Live RF in: Ant
Ref Lvl: 10 Preamp: Off Scale: 20 Set Ref Mode
Edit Return
Ho l d
Co ntr ol
41 20 29
(RF Mode)
SCREEN FEATURE FUNCTION
Gen Lvl Used to select the Tracking Generator output level.
Select: -65 to -5 dBm in 1 dB increments
125.74 to 125743.34
μV in 1 dB increments
dBm / μV
Used to select the units of measure for the Tracking Generator level.
Select: dBm or μV
Type Used to select the display type.
Select: Diff or Live
RF in Used to select the Tracking Generator input connector.
Select: Ant or T/R
Ref Lvl Used to select the top of screen reference level.
Select: -70 to 10 dBm in 10 dB increments
Preamp Used to set preamp operation ON or OFF.
Scale Used to select the dB/Div of the vertical axis.
Select: 2, 5, 10, 15 or 20
Set Ref Mode Used to set the Reference level.
F1 “Edit” / “Done” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
To Next Page
