Subject to Export Control, see Cover Page for details. 4-25
4-5-2. TRACKING GENERATOR SCREEN FEATURES AND FUNCTIONS (cont)
SCREEN FEATURE FUNCTION
F2 “Return” / “Save” Return Displays the System Menu (para 2-2-2)
Save Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data
dump is stored in a time-stamped ASCII report and can be
retrieved at a later time.
F3 “Hold” / “Resume” Hold Freezes the screen.
Resume Restores the screen to active mode.
F5 “Control” / “Marker” /
“RF” / “Esc”
Control Used to change the displayed fields and functionality on
the Tracking Generator Screen to Control Mode.
Marker Used to change the displayed fields and functionality on
the Tracking Generator Screen to Marker Mode.
RF Used to change the displayed fields and functionality on
the Tracking Generator Screen to RF Mode.
Esc Ends the Field Edit, but does NOT save any changes to the
setting or value.
