4-26 Subject to Export Control, see Cover Page for details.
4-5-2. TRACKING GENERATOR SCREEN FEATURES AND FUNCTIONS (cont)
TRACKING GENERATO
10
dB
-110
491.0 MHz 511.0
Freq (MHz): 501 .00 000 0 Sp an (MHz): 20 MHz
Sta rt (MHz): 491.0 00 000 Stop (M Hz): 511.0 000 00
Edit Return
Ho l d
Ma r ke r
41 20 29
(Control Mode)
SCREEN FEATURE FUNCTION
Freq (MHz) Used to select the Tracking Generator frequency.
Select: 2 to 1000 MHz in 0.000001 MHz increments (floating)
Span (MHz) Used to select the frequency span.
Select: 10 kHz, 20 kHz, 50 kHz, 100 kHz, 200 kHz, 500 kHz,
1 MHz, 2 MHz, 5 MHz, 10 MHz, 20 MHz, 50 MHz, 100 MHz,
200 MHz, 500 MHz or 998 MHz
Start (MHz) Used to select/display the Start Frequency.
Select: 2 to 1000 MHz in 0.000001 MHz increments (floating)
Stop (MHz) Used to select/display the Stop Frequency.
Select: 2 to 1000 MHz in 0.000001 MHz increments (floating)
F1 “Edit” / “Done” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
F2 “Return” / “Save” Return Displays the System Menu (para 2-2-2)
Save Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data
dump is stored in a time-stamped ASCII report and can be
retrieved at a later time.
F3 “Hold” / “Resume” Hold Freezes the screen.
Resume Restores the screen to active mode.
