4-32 Subject to Export Control, see Cover Page for details.
4-6-2. P25 MINI METER FEATURES AND FUNCTIONS
P2 5 Demo d Mo re
Sig Pwr - - -
Freq Err - - -
Mo d Fidly - - -
Deviation - - -
P2 5 Demo d Mo re
BER - - -
NAC - - -
Pa ttern 1011
Reset Acq
SCREEN FEATURE FUNCTION
Sig Pwr Displays the RF level at the input connector.
Freq Err Displays the frequency error of the transmitted signal.
Mod Fidly Displays the P25 waveform modulation fidelity.
Deviation Displays the symbol deviation accuracy.
BER Displays the incoming P25 symbol data compared to a standard
pattern in determining errors in signal processing.
NAC Displays the Network Access Code.
Pattern Used to set the data or voice pattern.
Select: 1011, 0.153 or CAL
Reset Acq Used to reacquire the input signal.
