4-6-3. DIGITAL RECEIVE (P25) SCREEN FEATURES AND FUNCTIONS
Edit Hold Re tur n
Di
g
it al Re ceive
P25 Demod Lower Upper Li
m i t
Reading Li
m i t Li m i t S tate Avg
Freq Err: -2.0 H
z -800.0 800.0 Off 1
Mo d Fidly: 0 .5 % 0 .0 100. 0 Of f 1
De v : 18 09 H
z 0 9 999 Of f 1
Sig Pwr: -1.5 dBm -130.0 60.0 Of f 1
BER: 0.000 % 0.000 100.000 Off 1
NA C: 2 39
Pat tern: 10 11
Re s et A cq
41 20 29
SCREEN FEATURE FUNCTION
Freq Err Used to select the parameters of the frequency error of the
transmitted signal.
Lower Limit: -800.0 to 800.0 Hz in 0.1 Hz increments
Upper Limit: -800.0 to 800.0 Hz in 0.1 Hz increments
Limit State: On or Off
Avg: 1 to 99
Mod Fidly Used to select the parameters of the P25 waveform modulation
fidelity.
Lower Limit: 0.0% to 100.0% in 0.1% increments
Upper Limit: 0.0% to 100.0% in 0.1% increments
Limit State: On or Off
Avg: 1 to 99
Dev Used to select the parameters of the symbol deviation accuracy.
Lower Limit: 0 to 9999 Hz in 1 Hz increments
Upper Limit: 0 to 9999 Hz in 1 Hz increments
Limit State: On or Off
Avg: 1 to 99
