4-38 Subject to Export Control, see Cover Page for details.
4-7-3. DIGITAL RECEIVE (DMR) SCREEN FEATURES AND FUNCTIONS (cont)
SCREEN FEATURE FUNCTION
Signal Pwr Used to select the parameters of the RF level at the input connector.
Lower Limit: -130.0 to 60.0 dBm in 0.1 dB increments
Upper Limit: -130.0 to 60.0 dBm in 0.1 dB increments
Limit State: On or Off
Avg: 1 to 99
BER Used to select the parameters of the incoming DMR symbol data
compared to a standard pattern in determining errors in signal
processing.
Lower Limit: 0.000% to 100.000% in 0.001% increments
Upper Limit: 0.000% to 100.000% in 0.001% increments
Limit State: On or Off
Avg: 1 to 99
Slot1 Pwr Used to select the parameters of the Slot1 power measurement.
Lower Limit: -130.0 to 60.0 dBm in 0.1 dB increments
Upper Limit: -130.0 to 60.0 dBm in 0.1 dB increments
Limit State: On or Off
Avg: 1 to 99
Slot2 Pwr Used to select the parameters of the Slot2 power measurement.
Lower Limit: -130.0 to 60.0 dBm in 0.1 dB increments
Upper Limit: -130.0 to 60.0 dBm in 0.1 dB increments
Limit State: On or Off
Avg: 1 to 99
Mag Error Used to select the parameters of the magnitude error.
Lower Limit: 0.00% to 100.00% in 0.01% increments
Upper Limit: 0.000% to 100.000% in 0.01% increments
Limit State: On or Off
Avg: 1 to 99
Color Code Used to select the Color Code.
Select: 0 to 15
Call ID Used to select the Call Identification value.
Select: 00000000 to 16777215
Radio ID Used to select the Radio Identification value.
Select: 0 to 15
