4-7-3. DIGITAL RECEIVE (DMR) SCREEN FEATURES AND FUNCTIONS (cont)
SCREEN FEATURE FUNCTION
Pattern Used to set the data or voice pattern.
Select: 1031, BR (Base Radio), 0.153 or CAL
Reset Acq Used to reacquire the input signal.
F1 “Edit” / “Done” /
“Enter” / “Save”
Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
Enter Initiates the selected field.
Save Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data
dump is stored in a time-stamped ASCII report and can be
retrieved at a later time.
F2 “Resume” Resume Restores the screen to active mode.
F3 “Hold” Hold Freezes the screen.
F5 “Return” / “Esc” Return Closes the Digital Receive Screen and returns to the Test
Screen.
Esc Ends the Field Edit, but does NOT save any changes to the
setting or value.
