4-46 Subject to Export Control, see Cover Page for details.
4-9-2. dPMR MINI METER FEATURES AND FUNCTIONS
dP MR De mo d Mo re
Sig Pwr -1.0
Fr eq Err -0 .1
FSK Err 1.1
Sym Dev 1058
dPMR Demod Mo re
BER 0.0 00
Pat tern 0.15 3
Reset Acq
SCREEN FEATURE FUNCTION
Sig Pwr Displays the RF level at the input connector.
Freq Err Displays the frequency error of the transmitted signal.
FSK Err Displays the FSK Error of the transmitted signal.
Sym Dev Displays the symbol deviation accuracy.
BER Displays the incoming dPMR symbol data compared to a standard
pattern in determining errors in signal processing.
Pattern Used to set the data or voice pattern.
Select: 0.153
Reset Acq Used to reacquire the input signal.
