4-9-3. DIGITAL RECEIVE (dPMR) SCREEN FEATURES AND FUNCTIONS
Edit Hold Re tur n
Di
g
it al Re ceive
DP MR De mo d L owe r U pp er L i
m i t
Reading Li
m i t Li m i t S tate Avg
Freq Error: 0.4 H
z -800.0 800.0 Off 1
FSK Error: 1.1 % 0.0 100.0 Off 1
Sym Dev: 1058 H
z 0 9 999 Of f 1
Signal Pwr: -1.0 dBm -130.0 60.0 Of f 1
BER: 0.000 % 0.000 100.000 Off 1
Pat tern: 0.1 53
Re s et A cq
41 20 29
SCREEN FEATURE FUNCTION
Freq Error Used to select the parameters of the frequency error of the
transmitted signal.
Lower Limit: -800.0 to 800.0 Hz in 0.1 Hz increments
Upper Limit: -800.0 to 800.0 Hz in 0.1 Hz increments
Limit State: On or Off
Avg: 1 to 99
FSK Error Used to select the parameters of the FSK error of the transmitted
signal.
Lower Limit: 0.0% to 100.0% in 0.1% increments
Upper Limit: 0.0% to 100.0% in 0.1% increments
Limit State: On or Off
Avg: 1 to 99
Sym Dev Used to select the parameters of the symbol deviation accuracy.
Lower Limit: 0 to 9999 Hz in 1 Hz increments
Upper Limit: 0 to 9999 Hz in 1 Hz increments
Limit State: On or Off
Avg: 1 to 99
