4-10-2. ARIBT98 MINI METER FEATURES AND FUNCTIONS
ARIB Demod More
Sig Pwr -1.1
Fr eq Err -3 .9
FSK Err 1.2
Sym Dev 948
ARIB Demod Mo re
BER 0.0 00
Pat tern 1031
Reset Acq
SCREEN FEATURE FUNCTION
Sig Pwr Displays the RF level at the input connector.
Freq Err Displays the frequency error of the transmitted signal.
FSK Err Displays the FSK Error of the transmitted signal.
Sym Dev Displays the symbol deviation accuracy.
BER Displays the incoming ARIBT98 symbol data compared to a standard
pattern in determining errors in signal processing.
Pattern Used to set the data or voice pattern.
Select: 1031, 0.153 or CAL
Reset Acq Used to reacquire the input signal.
To Next Page
