4-10-3. DIGITAL RECEIVE (ARIBT98) SCREEN FEATURES AND FUNCTIONS
Edit Hold Re tur n
Di
g
it al Re ceive
ARIB Demod Lower Upper Li
m i t
Reading Li
m i t Li m i t S tate Avg
Freq Error: -3.9 H
z -800.0 800.0 Off 1
FSK Error : 1.2 % 0 .0 1 00. 0 Of f 1
Sym Dev: 948 H
z 0 9999 Of f 1
Signal Pwr: -1.2 dBm -130.0 60.0 Of f 1
BER: 0.000 % 0.000 100.000 Off 1
Pat tern: 10 31
Re s et A cq
41 20 29
SCREEN FEATURE FUNCTION
Freq Error Used to select the parameters of the frequency error of the
transmitted signal.
Lower Limit: -800.0 to 800.0 Hz in 0.1 Hz increments
Upper Limit: -800.0 to 800.0 Hz in 0.1 Hz increments
Limit State: On or Off
Avg: 1 to 99
FSK Error Used to select the parameters of the FSK error of the transmitted
signal.
Lower Limit: 0.0% to 100.0% in 0.1% increments
Upper Limit: 0.0% to 100.0% in 0.1% increments
Limit State: On or Off
Avg: 1 to 99
Sym Dev Used to select the parameters of the symbol deviation accuracy.
Lower Limit: 0 to 9999 Hz in 1 Hz increments
Upper Limit: 0 to 9999 Hz in 1 Hz increments
Limit State: On or Off
Avg: 1 to 99
