Subject to Export Control, see Cover Page for details. C-27
C-4. REMOTE OPERATION COMMANDS (cont)
RF Generator
COMMAND RANGE DESCRIPTION
:gen:ant:protection? 0 - OFF
1 - ON (Overload)
Returns ANT Connector protection state.
:gen:ant:protection:reset Resets ANT Connector protection state.
:gen:atten? 0 to 63 dB Returns RF Generator attenuator setting.
:gen:dcpwr 0 - OFF
1 - ON
Sets RF Generator DC Power state.
:gen:extpad -30.0 to 30.0 dB Sets compensation of RF Generator output
level for external pad.
:gen:extpad? Returns value of compensation for external
pad.
:gen:freq 2.000000 to 1000.000000 MHz Sets RF Generator frequency.
:gen:freq? Returns RF Generator frequency.
:gen:lvl:dbm SWR - -65 to -5 dBm
T/R - -120 to -50 dBm
ANT - -90 to -30 dBm
Sets RF Generator level on selected output
connector.
:gen:lvl:dbm? Returns RF Generator level on selected output
connector.
:gen:lvl:unit 0 - dBm
1 - μV
Sets RF Generator level units to μ V or dBm.
:gen:lvl:uv
SWR - 125.74 to 125743.34 μV
T/R - 0.22361 to 707.11 μV
ANT - 7.071 to 7071.07 μV
Sets RF Generator level on selected output
connector.
:gen:lvl:uv? Returns RF Generator level on selected output
connector.
:gen:port 0 - T/R
1 - ANT
2 - SWR
Sets RF Generator Output Connector.
:gen:port? Returns RF Generator Output Connector
selected.
:gen:port:protection 0 - OFF
1 - RESET
2 - ON
Resets SWR Connector protection circuit.
:gen:swr:protection? 0 - OFF
1 - ON (Overload)
Returns SWR Connector protection state.
:gen:swr:protection:reset Resets SWR Connector protection state.
:gen:tr:protection? 0 - OFF
1 - ON (Overload)
Returns T/R Connector protection state.
:gen:tr:protection:reset Resets T/R Connector protection state.
