C-4. REMOTE OPERATION COMMANDS (cont)
RF Power Meter
COMMAND RANGE DESCRIPTION
:rfpow:alarm:high:limit 1.0 to 43.0 dBm
0.1 to 20.0 W
Sets Alarm high limit value.
:rfpow:alarm:high:limit? Returns Alarm high limit value.
:rfpow:alarm:high:state Sets Alarm high limit state.
:rfpow:alarm:high:state? Returns Alarm high limit state.
:rfpow:alarm:low:limit 1.0 to 43.0 dBm
0.1 to 20.0 W
Sets Alarm low limit value.
:rfpow:alarm:low:limit? Returns Alarm low limit value.
:rfpow:alarm:low:state Sets Alarm low limit state.
:rfpow:alarm:low:state? Returns Alarm low limit state.
:rfpow:average 1 to 99 Sets number of readings to average.
:rfpow:average? Returns number of readings to average.
:rfpow:cal:freq:resp? Returns frequency in MHz at supplied index.
:rfpow:cal:lin:high:calpt Takes current high power reading and supplied
cal value at supplied index.
:rfpow:cal:lin:high:dac? Returns DAC value at supplied index.
:rfpow:cal:lin:high:pow? Returns dBm value at supplied index.
:rfpow:cal:lin:high:size Clears previous high range cal curve and
resizes as required.
:rfpow:cal:lin:high:size? Returns high power cal curve size.
:rfpow:cal:lin:low:calpt Takes current low power reading and supplied
cal value at supplied index.
:rfpow:cal:lin:low:dac? Returns dac value at supplied index.
:rfpow:cal:lin:low:pow? Returns dBm value at supplied index.
:rfpow:cal:lin:low:size Clears previous low range cal curve and
resizes as required.
:rfpow:cal:lin:low:size? Returns low power cal curve size.
:rfpow:cal:recalc Recalculates Calibration.
:rfpow:cal:recall Recalls Calibration Data.
:rfpow:cal:resp:calpt Takes correction freq and index to fill cal
table.
:rfpow:cal:resp:calpt? Returns cal factor value at supplied index.
:rfpow:cal:resp:size Clears previous response cal curve and
resizes as required.
:rfpow:cal:resp:size? Returns response cal curve size.
:rfpow:cal:save Saves Calibration Data.
:rfpow:cal:state 0 - Normal PT Operation
1 - Range Cal
2 - Response Cal
Sets Calibration State
:rfpow:cal:state? Returns Calibration State.
:rfpow:extatten -30.0 to +30.0 dB Sets compensation factor for external
attenuation.
:rfpow:extatten? Returns compensation factor for external
attenuation.
:rfpow:range 0 - Low Range
1 - High Range
2 - Auto Range
Sets reading range operation.
:rfpow:range:dbm:range? Returns RF Power Meter range information.
:rfpow:range:dbm:auto Sets RF Power Meter autorange state to Auto.
:rfpow:range:dbm:manual Sets RF Power Meter autorange state to
Manual.
