C-40 Subject to Export Control, see Cover Page for details.
C-4. REMOTE OPERATION COMMANDS (cont)
Spectrum Analyzer
COMMAND RANGE DESCRIPTION
:analyzer:avg 1 to 99 Sets Spectrum Analyzer average.
:analyzer:avg? Returns Spectrum Analyzer average.
:analyzer:current:avg? 0 to 99 Returns number of traces for current Spectrum
Analyzer trace reading.
:analyzer:freq 2 to 1000 MHz Sets Spectrum Analyzer center frequency.
:analyzer:freq? Returns Spectrum Analyzer center frequency.
:analyzer:marker:freq 2 to 1000 MHz Sets Spectrum Analyzer marker center
frequency.
:analyzer:marker:freq? Returns Spectrum Analyzer marker center
frequency.
:analyzer:psd 0 - Spectrum
1 - Power Spectral Density
Sets Spectrum Analyzer power spectral density.
:analyzer:psd? Returns Spectrum Analyzer power spectral
density.
:analyzer:peakhold 0 - OFF
1 - ON
Activates Spectrum Analyzer peak hold.
:analyzer:peakhold? Returns Spectrum Analyzer peak hold status.
:analyzer:pwrbwspan 1000 Hz
2000 Hz
5000 Hz
10000 Hz
20000 Hz
50000 Hz
100000 Hz
200000 Hz
500000 Hz
1000000 Hz
2000000 Hz
5000000 Hz
Sets Spectrum Analyzer power bandwidth span.
:analyzer:pwrbwspan? Returns Spectrum Analyzer power bandwidth
span.
:analyzer:reading:bwpwr? in dBm Returns Spectrum Analyzer bandwidth power.
:analyzer:reading:rbwe? in Hz Returns Spectrum Analyzer resolution bandwidth
equivalent.
:analyzer:sleep
10000 to 500000 μs
Sets Spectrum Analyzer sleep time.
:analyzer:sleep? Returns Spectrum Analyzer sleep time.
:analyzer:span 10000 Hz
20000 Hz
50000 Hz
100000 Hz
200000 Hz
500000 Hz
1000000 Hz
2000000 Hz
5000000 Hz
Sets Spectrum Analyzer span.
:analyzer:span? Returns Spectrum Analyzer span.
:analyzer:state Activates Spectrum Analyzer signal processing.
:analyzer:state? Returns Spectrum Analyzer signal processing
state.
:analyzer:trace:amplitude? Returns Spectrum Analyzer trace amplitude.
:analyzer:trace:frequency? Returns Spectrum Analyzer trace frequency.
