Subject to Export Control, see Cover Page for details. C-43
C-4. REMOTE OPERATION COMMANDS (cont)
Upconverter
COMMAND RANGE DESCRIPTION
:upconverter:carrier_state Acts as a PTT. Needs to be ON for normal
Generator operation.
:upconverter:carrier_state? Returns carrier state.
:upconverter:dcs:am 0% to 100% Sets Modulator DCS AM level.
:upconverter:dcs:fm 0.0 to 100.0 kHz Sets Modulator DCS FM level.
:upconverter:dcs:state Sets Modulator DCS Signaling State.
:upconverter:dtmf:am:high 0% to 100% Sets Modulator DTMF AM high level.
:upconverter:dtmf:am:low 0% to 100% Sets Modulator DTMF AM low level.
:upconverter:dtmf:fm:high 0.0 to 100.0 kHz Sets Modulator DTMF FM high level.
:upconverter:dtmf:fm:low 0.0 to 100.0 kHz Sets Modulator DTMF FM low level.
:upconverter:ext_aud_in:gain 0.0 to 1.0 Sets Modulator External Audio Input Raw Scaling.
:upconverter:ext_aud_in:state Sets Modulator External Audio Input State.
:upconverter:fgen1:am 0% to 100% Sets Modulator fgen #1 AM level.
:upconverter:fgen1:fm 0.0 to 100.0 kHz Sets Modulator fgen #1 FM level.
:upconverter:fgen1:freq 0 to 24000 Hz Sets Modulator fgen #1 frequency.
:upconverter:fgen1:gain 0.0 to 1.0 Sets Modulator fgen #1 Raw Scaling.
:upconverter:fgen1:state Sets Modulator fgen #1 ON/OFF.
:upconverter:fgen2:am 0% to 100% Sets Modulator fgen #2 AM level.
:upconverter:fgen2:fm 0.0 to 100.0 kHz Sets Modulator fgen #2 FM level.
:upconverter:fgen2:freq 0 to 24000 Hz Sets Modulator fgen #2 frequency.
:upconverter:fgen2:gain 0.0 to 1.0 Sets Modulator fgen #2 Raw Scaling.
:upconverter:fgen2:state Sets Modulator fgen #2 ON/OFF.
:upconverter:mic:am 0% to 100% Sets Modulator Microphone AM level.
:upconverter:mic:fm 0.0 to 100.0 kHz Sets Modulator Microphone FM level.
:upconverter:mic:gain 0.0 to 1.0 Sets Modulator Microphone State.
:upconverter:mic:select? Returns the Microphone connected.
:upconverter:mic:state Sets Modulator Microphone State.
:upconverter:mod_inhibit Disables modulation for one-time calibrations.
:upconverter:mod_inhibit? Returns modulation inhibit state.
:upconverter:route:enable Sets Modulator ON/OFF.
:upconverter:sde:am 0% to 100% Sets SDE AM level.
:upconverter:sde:fm 0.0 to 100.0 kHz Sets SDE FM level.
:upconverter:sde:gain 0.0 to 1.0 Sets SDE Gain ffff Scaling.
:upconverter:sde:state Sets SDE State ON/OFF.
:upconverter:type 0 - AM
1 - FM
2 - None
3 - P25
4 - SDE-AM
5 - SDE-FM
6 - Invalid
Sets Modulator type.
:upconverter:type? Returns Modulator type.
