C-44 Subject to Export Control, see Cover Page for details.
C-4. REMOTE OPERATION COMMANDS (cont)
VSWR Meter
COMMAND RANGE DESCRIPTION
:vswr:cable:len Estimates cable length to measure.
:vswr:cablelength2span? in feet Returns Cable Length to Span.
:vswr:cable:loss in dB Sets cable attenuation per 100 feet.
:vswr:cable:velocity [0.0, 1.0] Sets cable velocity factor.
:vswr:cal:save Saves Calibration data.
:vswr:cal:recall Recalls Calibration data.
:vswr:complete? 0% to 100% Returns the progress of the sweep through the
selected bandwidth.
:vswr:freq Sets center frequency.
:vswr:freq? Returns center frequency.
:vswr:marker:delta 1 to 3 Sets Delta Marker.
:vswr:marker:delta:x? 1 to 3 Returns marker delta number at x axis.
:vswr:marker:delta:y? 1 to 3 Returns marker delta number at y axis.
:vswr:marker:enable 1 to 3 Enables Marker.
:vswr:marker:left 1 to 3 Moves marker to the left.
:vswr:marker:lmin 1 to 3 Moves marker to next left min.
:vswr:marker:lpk 1 to 3 Moves marker to next left peak.
:vswr:marker:max 1 to 3 Moves marker to maximum.
:vswr:marker:min 1 to 3 Moves marker to minimum.
:vswr:marker:pos Sets horizontal position of current Marker.
:vswr:marker:right 1 to 3 Moves marker to the right.
:vswr:marker:rpk 1 to 3 Moves marker to next right peak.
:vswr:marker:rmin 1 to 3 Moves marker to next right min.
:vswr:marker:x? 1 to 3 Returns marker number at x axis.
:vswr:marker:y? 1 to 3 Returns marker number at y axis.
:vswr:meas:type 0 - SWR
1 - DTF
2 - RL
3 - LOSS
4 - Calibration
5 - Raw
Selects type of measurement.
:vswr:meas:type? Returns type of measurement.
:vswr:postprocess 0 - INVALID_CIRCUIT
1 - OPEN_CIRCUIT
2 - SHORT_CIRCUIT
3 - FIFTY_OHM_CIRCUIT
4 - LOAD_CIRCUIT
Sets Post Process state.
:vswr:runmode 0 - RESULT_INVALID
1 - REQUEST_RUNNING
2 - RUNNING
3 - STOPPED
4 - REQUEST_STOP
Sets Run mode.
:vswr:scale 1 - Top
2 - Bottom
Sets scale for vertical.
:vswr:size? 2 to 512 Returns SWR trace length.
:vswr:span Sets span.
:vswr:span? Returns span.
:vswr:span2cablelength? in MHz Returns Calculated Span to Cable Length.
:vswr:start Sets start frequency.
:vswr:start? Returns start frequency.
:vswr:startsweep Starts sweep.
