Subject to Export Control, see Cover Page for details. C-45
C-4. REMOTE OPERATION COMMANDS (cont)
VSWR Meter (cont)
COMMAND RANGE DESCRIPTION
:vswr:state 0 - RESULT_INVALID
1 - REQUEST_RUNNING
2 - RUNNING
3 - STOPPED
4 - REQUEST_STOP
Sets VSWR state.
:vswr:state? Returns VSWR state.
:vswr:stop Sets stop frequency.
:vswr:stop? Returns stop frequency.
:vswr:stopsweep Stops sweep.
:vswr:trace:count? 0 to 4294967295 Returns trace count of each trace completed then
counts increments.
:vswr:trace:dtf? 0 to trace size minus one
-50 to 0 dB
Returns DTF trace values by index.
(See :vswr:size? command.)
:vswr:trace:loss? 0 to trace size minus one
-5 to 0 dB
Returns LOSS trace values by index.
(See :vswr:size? command.)
:vswr:trace:rtn_loss? 0 to trace size minus one
-5 to 0 dB
Returns Return Loss trace values by index.
(See :vswr:size? command.)
:vswr:trace:size? 2 to 512 Returns SWR trace length.
:vswr:trace:vswr? 0 to trace size minus one
SWR: 1 to 6
Returns SWR trace values by index.
(See :vswr:size? command.)
:vswr:trace:vswr_dump? Returns VSWR trace values.
:vswr:units 0 - Feet
1 - Meters
Sets the units of measure.
:vswr:val? 0 to trace size minus one
SWR: 1 to 6
Returns SWR trace values by index.
(See :vswr:size? command.)
