CHAPTER 2 - OPERATING INSTRUCTIONS
Subject to Export Control, see Cover Page for details. 2-1
062-006b
3500
AUDIO OUT
AUDIO IN
DVM
1
2
3
4
5
6
7
8
9
0
(3500A)
(3500)
14
15
16
17
18
19
10
11
12
13
7
8
9
1
5
3
2
4
6
20
22
21
(3500A ONLY)
2-1. OPERATOR’S CONTROLS, INDICATORS AND CONNECTORS
1 ANT Connector
2 T/R Connector
3 DC IN Connector
4 AUDIO Connector
5 SWR Connector
6 REMOTE Connector
7 Display (LCD)
8 Multi-Function Soft Keys
9 Number Keys
10 CONTRAST / • Key
11 BACKLIGHT / ± Key
12 CHARGE Indicator
13 POWER Key
14 POWER Indicator
15 FAULT Indicator
16 DOWN Key
17 LEFT Key
18 RIGHT Key
19 UP Key
20 DVM Connector
21 AUDIO IN Connector
22 AUDIO OUT Connector
Figure 2-1. Controls, Connectors and Indicators
