B. Receiver Test Screen (cont)
SCREEN FEATURE FUNCTION
Meters (not shown) Several Meters can be selected to appear on the Receiver Test
Screen.
Meters are selected in the Receiver Test Setup Screen.
F1 “Edit” / “Done” / “Zoom” /
“Enter”
Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
Zoom Displays the screen of the field selected.
Enter Moves cursor into meter / function on test screen.
F2 “Return” / “Save” Return Displays the System Menu (para 2-2-2)
Save Performs a data dump of frames displayed on the screen.
Meters save configurations and readings. Control frames
save settings. The data dump is stored in a time-stamped
ASCII report and can be retrieved at a later time.
F3 “Hold” / “Resume” Hold Freezes the screen.
Resume Restores the screen to active mode.
F4 “Setup” Displays the Receiver Test Setup Screen.
F5 “Esc” Ends the Field Edit, but does NOT save any changes to the setting
or value.
