2-32 Subject to Export Control, see Cover Page for details.
D. ANT-Cable Test Screen (cont)
SCREEN FEATURE FUNCTION
Start Used to select/display the Start Frequency.
Range: 2.0 to 1000 MHz in 0.1 MHz increments
Displays the Start Frequency entered by the operator or the
calculated Start Frequency if the Center Frequency and Frequency
Span are entered.
Stop Used to select/display the Stop Frequency.
Range: 2.0 to 1000 MHz in 0.1 MHz increments
Displays the Stop Frequency entered by the operator or the calculated
Stop Frequency if the Center Frequency and Frequency Span are
entered.
F1 “Edit” / “Done” / “Next” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
Next Displays the next pop-up screen.
F2 “Return” / “Save” Return Displays the System Menu (para 2-2-2)
Save Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data
dump is stored in a time-stamped ASCII report and can be
retrieved at a later time.
F3 “Hold” / “Resume” /
“Abort”
Hold Freezes the screen.
Resume Restores the screen to active mode.
Abort Stops the action to calibrate the SWR Connector.
F4 “Cal” Instruction pop-ups are displayed to calibrate the SWR Connector.
F5 “Marker” / “Scale”
“RF” / “Esc”
Marker Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to Marker Mode.
Scale Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to Scale Mode.
RF Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to RF Mode.
Esc Ends the Field Edit, but does NOT save any changes to
the setting or value.
