D. ANT-Cable Test Screen
When the System Menu is displayed, press the 4 Key to access the ANT-Cable Test Screen:
ANT-CABL E TEST
7.0 0
2009-01 -06
11:35:30
SWR
1.0 0
35.0 MHz 45.0
Type: SWR Freq (MHz): 40.0 Span (MHz): 10.0
Start (MHz): 35.0 Stop (MHz): 45.0
Edit Return
Ho l d
Cal
ar
er
41 20 29
(RF Mode)
SCREEN FEATURE FUNCTION
VSWR Progress Bar A graphical representation of the percentage completed for the
current measurement.
Type Used to select the mode of testing.
Select: SWR, DTF, RL, LOSS or Raw
Freq Used to select/display the Center Frequency.
Range: 2.0 to 1000.0 MHz in 0.1 MHz increments
Displays the Center Frequency entered by the operator or the
calculated Center Frequency if the Start and Stop Frequencies are
entered.
Span Used to select/display the Frequency Span.
Range: (SWR) 10 to 998 MHz in 0.1 MHz increments
(DTF) 100 to 998 MHz in 0.1 MHz increments
(RL) 10 to 998 MHz in 0.1 MHz increments
(LOSS) 10 to 998 MHz in 0.1 MHz increments
Displays the Frequency Span entered by the operator or the
calculated Frequency Span if the Start and Stop Frequencies are
entered.
To Next Page
