C. Transmitter Test Screen (cont)
SCREEN FEATURE FUNCTION
Audio Level Used to select the position of the Audio Level Meter on the
Transmitter Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
Meter Chart Displays the areas of the Transmitter Test Screen and a number
representing each area (i.e., 3 is top right on the Transmitter Test
Screen, etc.).
F1 “Edit” / “Done” Edit Highlights the selected field to be changed.
Done Ends the Field Edit and saves the new setting / value.
F2 “Return” Displays the Transmitter Test Screen.
F5 “Esc” Ends the Field Edit, but does NOT save any changes to the setting or
value.
