Aeroflex 3500A - Page 69

Subject to Export Control, see Cover Page for details. 2-29
C. Transmitter Test Screen (cont)
SCREEN FEATURE FUNCTION
Fgen (Function Generator) Used to select the position of the Function Generator on the
Transmitter Test Screen (refer to Meter Chart).
Since the Function Generator occupies the screen space of two
functions on the Transmitter Test Screen, the space directly adjacent
to the screen space selected must be empty in order for the Function
Generator to be displayed. (e.g. To select screen space 2; screen
space 3 must be empty)
Select: 0 (Meter not shown), 2, 4, 5 or 8
Status Select: On or Off
Freq Select: 0 to 20000 Hz in 0.1 Hz increments
Level Select: 0.00 to 1.57 Vrms in 0.01 V increments
The Function Generator utilizes the AUDIO Connector for signal
output.
Modulation Meter Used to select the position of the Modulation Meter on the Transmitter
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
RSSI Meter Used to select the position of the RSSI Meter on the Transmitter Test
Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
RF Error Meter Used to select the position of the RF Error Meter on the Transmitter
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
Distortion Meter Used to select the position of the Distortion Meter on the Transmitter
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
SINAD Meter Used to select the position of the SINAD Meter on the Transmitter
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
RF Power Meter Used to select the position of the RF Power Meter on the Transmitter
Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
AF Counter Used to select the position of the AF Counter on the Transmitter Test
Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
DTMF Decode Used to select the position of the DTMF Decode Meter on the
Transmitter Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
DCS Decode Used to select the position of the DCS Decode Meter on the
Transmitter Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 2, 3, 4, 5, 6, 8 or 9
