2-44 Subject to Export Control, see Cover Page for details.
2-2-3. METERS MENU
When the System Menu, Self Test Menu or Utilities Menu is displayed, press the F2 “Meters” Key to
access the Meters Menu:
Me ter s Syste
m
Self test
Uti l
1 - SINAD
2 - DISTORTION
3 - AF COUNTER
4 - AUDIO LEVE L METER
SCREEN FEATURE FUNCTION
1 - SINAD Displays the SINAD Meter Screen (para 2-2-3A).
2 - DISTORTION Displays the Distortion Meter Screen (para 2-2-3B).
3 - AF COUNTER Displays the AF Counter Screen (para 2-2-3C).
4 - AUDIO LEVEL METER Displays the Audio Level Meter Screen (para 2-2-3D).
F2 “Meters” Displays the Meters Menu (para 2-2-3).
F3 “System” Displays the System Menu (para 2-2-2).
F4 “Selftest” Displays the Self Test Menu (para 2-2-4).
F5 “Util” Displays the Utilities Menu (para 2-2-5).
