E. Audio Function Generator Test Screen (cont)
SCREEN FEATURE FUNCTION
Audio Level Used to select the position of the Audio Level Meter on the Audio
Function Generator Test Screen (refer to Meter Chart).
Select: 0 (Meter not shown), 3, 4, 5, 6, 8 or 9
Meter Chart Displays the areas of the Audio Function Generator Test Screen and a
number representing each area (i.e., 3 is top right on the Audio
Function Generator Test Screen, etc.).
F1 “Edit” / “Done” Edit Highlights the selected field to be changed.
Done Ends the Field Edit and saves the new setting / value.
F2 “Return” Displays the Audio Function Generator Test Screen.
F5 “Esc” Ends the Field Edit, but does NOT save any changes to the setting or
value.
