B. Distortion Meter Screen (cont)
SCREEN FEATURE FUNCTION
Limits - Lower Used to enable the Distortion Meter Low Limit.
Select: 0.0% to 100.0% in 0.1% increments
Sets the marker on the Distortion Bar to the Lower Limit selected.
Limits - Upper Used to enable the Distortion Meter Upper Limit.
Select: 0.0% to 100.0% in 0.1% increments
Sets the marker on the Distortion Meter Bar to the Upper Limit
selected.
State - Lower Limit Used to display the Lower Limit Marker on the Distortion Meter Bar.
Select: On or Off
State - Upper Limit Used to display the Upper Limit Marker on the Distortion Meter Bar.
Select: On or Off
Distortion Meter Bar A graphical representation of the received Distortion Meter readings.
F1 “Edit” / “Done” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
F2 “Return” / “Save” Return Displays the System Menu (para 2-2-2)
Save Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data
dump is stored in a time-stamped ASCII report and can be
retrieved at a later time.
F3 “Hold” / “Resume” Hold Freezes the screen.
Resume Restores the screen to active mode.
F5 “Return” / “Esc” Return Closes the Distortion Meter Screen and returns to the Test
Screen.
Esc Ends the Field Edit, but does NOT save any changes to the
setting or value.
To Next Page
