MAI NTENANCE MANUAL
ATC-1400A-2
2-2-2
Page 5 4
Subj e c t to E x p o rt Con t r o l, s e e C o ver P a g e fo r d e tail s . F e b 2/ 0 9
STEP DATA RESULT
29. IDENT T o n e is 2 7 0 0 Hz ( ±0 . 54 Hz ) . ____ _ _ _ _
32. Eq u a l ize r p uls e s pac i n g is 1 0 0 µs (±10 µs) ____ _ _ _ _
36. Sq u i t t er f r e q uen c y 2700 H z (±29 Hz ) __ _ ___ _ _
38. PRF / S Q T R t humbwhe e l s ett i n g s tr a c k fre q u e ncy
c o u n ter d i spl a y ____ _ _ _ _ ( √)
(10) 50 % V ideo S l i cer a n d Tran s mi t t e r Po we r
5. 50% v i deo p u lse a l i gns w i t h Gau s s i an s h a ped p u l se a t
5 0 % p oin t ____ _ _ _ _ ( √)
6. 0.75 V p - p ( t y p i cal ) a t 100 0 W __ ____ _ _ (√)
9. 50% v i deo p u lse i s ≥9. 5 g rat i c u les l o n g ____ _ _ _ _
12. 50 % v ide o p u lse d o es n o t osc i l l ate o r disa p p e ar. _____ _ _ _ (√)
Slic e r qui t s b etwee n 1 and 2 W re a d i ng _ _ _ ____ _ (√)
16. Pu l s e d RF P o w e r Sour c e L eve l r e fer e n c e ____ _ _ _ _
18. XMTR P OW E R W A TTS D i s p lay i n dica t e s 10x l e ss t h a n
St e p 16 r e a d ing w i t h inp u t p ower d e c reas e d 10 d B . ____ _ _ _ _ ( √)
XMTR POWER W A T T S Dis p l a y in d i c a tes 1 0 x more t h a n
S t e p 16 r e a d ing w i t h inp u t power i n c rea s e d 10 d B . ____ _ _ _ _ ( √)
(11) Di s c rimina t o r Fre q u e ncy
5. P
1
pul s e is d i s pla y e d . __ _ ___ _ _ (√)
7. P
2
pul s e is d i s pla y e d . __ _ ___ _ _ (√)
10. F
2
pul s e is d i s pla y e d . ___ _ _ _ __ ( √)
11. F
2
pul s e is d i s pla y e d be t w e e n 19 . 8 (±0. 2 µs) a n d
2 2 µs ( ±0 . 4 µs ). ____ _ _ _ _ ( √)
12. F
1
pul s e is d i s pla y e d . ___ _ _ _ __ ( √)
20. Fr e q u enc y d isp l a y ed o n X MTR FREQ MHz Dis p l a y i s
wi t h i n ±20 k H z o f fr e q u e ncy o n D I S PLA Y S E LECT
Rea d o u t. __ _ ____ _
21. Fr e q u enc y d isp l a y ed o n X MTR FREQ MHz Dis p l a y i s
wi t h i n ±20 k H z o f fr e q u e ncy o n D I S PLA Y S E LECT
Rea d o u t. __ _ ____ _
22. XMTR F RE Q MHz Di s p l ay i s with i n ±20 k H z of
fr e q u ency o n D I SPLA Y S E LECT Re a d o u t. ______ _ _ (√)
23. XMTR F RE Q MHz Di s p l ay i s with i n ±20 k H z of
fr e q u ency o n D I SPLA Y S E LECT Re a d o u t. ______ _ _ (√)
25. XMTR F RE Q MHz Di s p l ay i s with i n ±20 k H z of
f r e q u enc y i n St e p 21. ____ _ _ _ _ ( √)
