SECTION 5 REPLACEMENT PROCEDURES
DC Fan Assembly I
Preliminary Procedure: Remove Rear Panel Assembly (p. 5-9)
Remove Can Cover Assembly (p. 5-10)
STEP
PROCEDURE
1.
Remove wire harnesses
CD
CZl
~.
2.
With the 2398 stood on its front panel, remove six screws @ and ten screws
®.
3. Remove rear frame assembly
CW.
4. Remove four nuts (f).
5.
Remove the assembly as shown.
5-37
