VERIFICATION
IFR 4000
Subject to Export Control, see Cover Page for details. Page 8
Jun 1/11
STEP PROCEDURE
57. Set the RF LVL Field to the following settings and verify levels on the Power
Meter:
RF LVL LEVEL
-57 dBm
-57 dBm (±3 dB)
-47 dBm
-47 dBm (±3 dB)
-37 dBm
-37 dBm (±3 dB)
-27 dBm
-27 dBm (±3 dB)
-17 dBm
-17 dBm (±3 dB)
-7 dBm
-7 dBm (±3 dB)
+3 dBm
+3 dBm (±3 dB)
+13 dBm
+13 dBm (±3 dB)
58. Set the RF LVL Field to -67 dBm.
59. Disconnect the Power Sensor from the ANT Connector and connect the
Measuring Receiver to the ANT Connector.
60. Calibrate the Measuring Receiver for 118.000 MHz in Tuned RF Level Mode.
61. Verify -67 dBm (±3 dB) on the Measuring Receiver.
62. Disconnect the Measuring Receiver from the ANT Connector.
