20 mm searchlight
Order No. 566720
The searchlight swivels and tilts, and its articulation can be controlled by
mini-servos. The LED must be fitted with a series resistor!
Bend the sides of part 1 through 90° as shown. Insert the sides 2 and solder
the box joints on the inside. Pass the tube 4 through the box and the top
cover 3. Align the cover carefully before soldering it to the box from the
underside.
Solder the 1.5 mm brass rod 7 in the holes in the bracket arms 6 and 8, then
cut down the rods to a maximum length of 2 mm on the side with the etched-
in grooves. Sand or file it back flush with the bracket arms 6 and 8. Solder
the tubes 4 and 5 in the centre of parts 6 and 8. The tubes should project at
the top, but by no more than 1 mm. Glue the two tilt bushes 10 centrally to
the searchlight housing 9 using cyano. Drill 1.5 mm holes through the plastic
tube, then remove the drilling burr on the inside.
Fit the LED 14 in the reflector 15. Cut down the terminal pins attached to the
LED to a length of 7 - 8 mm, then solder the wires to the LED terminals, and
insulate the soldered joints. Bend the wires over at the reflector. Drill a 2 mm
Ø hole in the centre of the bottom of the searchlight housing for the wires to
pass through; the hole should be located behind the bracket 6. Pass the
cables through the hole and insert the reflector. Peel off the inner protective
film from the lens 16, and press the lens into place.
Complete the rear cover 11 by fitting the handles 12. Insert the rear cover in
the searchlight, and glue the latches 13 to the cover and the searchlight.
Bend the swivel and tilt brackets 6 / 8 through about 45° in the direction of
the grooves. Slide the tubes into each other, and allow the shafts to snap
into the tilt bushes 10. It should now be possible to tilt the searchlight by
moving the inner tube. Fit the tube through the box.
The searchlight can now be painted. Remove the protective film from the
lamp lens when the paint is dry. You will find two etched 1.0 mm holes on
either side of the rear cover 11 which are intended to help when replacing
the LED. If a repair is needed, drill out the holes and push a length of wire
through them to push out the reflector and lens.
Parts List for the searchlight, Order No. 566720
Part 4 774041 Brass tube, 4.0 x 0.45 x 40 mm
Part 5 774031 Brass tube, 3.0 x 0.45 x 60 mm
Part 7 773215 Brass tube, 1.5 x 20 mm
Part 9 772849 ASA tube, 20.0 x 18.0 x 20.0 mm
Part 14 5.0 mm LED
Part 15 Reflector
Part 16 Lens VIVAK 18.0 Ø x 1.0 mm
Specification
Voltage 5 V, only with 75 Ohm series resistor
6 V only with 120 Ohm series resistor
12 V only 430 Ohm series resistor
Length 27 mm
Width 22 mm
Height 45 mm
Swivel range 360°
Tilt range +/-15° max.
All of us in the aero-naut Modellbau team hope you have loads of pleasure building this model.
No. Description Quant. Material Sheet Dimensions
119 Seat front section 1 1.0 mm ABS 9
120 Seat side section 2 1.0 mm ABS 9 Two-part, engraved
121 Seat backrest 1 1.0 mm ABS 9 Two-part, engraved
122 Seat backrest side fairing 1 1.0 mm ABS 9 Two-part, engraved
123 Seat top cover 1 1.0 mm ABS 9
124 Seat floor plate 1 1.0 mm ABS 9
125 Seat footrest 1 1.0 mm ABS 9
126 Seat column 1 4.0 x 35 mm Dowel
127 Seat bottom 4 1.0 mm ABS 9
128 Seat squab 4 1.0 mm ABS 9
129 Seat front 4 1.0 mm ABS 9
130 Seat side 8 1.0 mm ABS 9 Two-part, engraved
131 Seat backrest 4 1.0 mm ABS 9 Two-part, engraved
132 Seat backrest fairing 4 1.0 mm ABS 9 Two-part, engraved
133 Seat top cover 4 1.0 mm ABS 9
134 Seat column 8 4.0 x 20 mm Dowel
135 Rear table side panel 4 1.0 mm ABS 9
136 Front table side panel 4 1.0 mm ABS 9
137 Table rear panel 4 1.0 mm ABS 9
138 Table front panel 4 1.0 mm ABS 9
139 Rear table top 2 1.0 mm ABS 9
140 Front table top 2 1.0 mm ABS 9
141 Inner mast section 2 1.5 mm ABS 3
142 Outer mast section 2 1.0 mm ABS 9
143 Spreader 2 1.5 mm ABS 3
144 GPS top section 1 1.5 mm ABS 3
145 GPS centre section 2 1.5 mm ABS 3
146 GPS column 1 3 x 23 mm Dowel
147 Mast locating pin 1 3 x 8 mm Dowel
148 Lamp bottom section 9 1.5 mm ABS 3
149 Lamp cover 9 1.5 mm ABS 3
150 Clear lamp lens 9 5.0 mm Plexiglas Ready made
151 Roof railing stanchion 3 1.5 x 40 mm Nickel-silver wire
152 Roof handrail, side 2 1.5 x 160 mm Nickel-silver wire
153 Roof handrail, rear 1 1.5 x 165 mm Nickel-silver wire
154 Aerial base 3 2 x 1 x 30 mm Plastic tube
155 Rod aerial 3 1 x 100mm Brass wire, overlength
156 Stern railing stanchion 8 0.5 mm nickel-silver Etched
157 Stanchion base 8 0.5 mm nickel-silver Etched
158 Handrail 1 1.2 x 500 mm Brass wire, overlength
159 Rail 2 0.8 x 500 mm Brass wire, overlength
160 Handrail stanchion 12 0.5 mm nickel-silver Etched
161 Handrail 2 1.2 x 250 mm Brass wire, overlength
162 Radar flange 2 1.5 mm ABS 3
163 Radar connecting tube 1 5 x 3 x 7 mm ABS tube
164 Radar unit 1 Ready made 5686/01
165 Searchlight 1 Ready made 5667/20
166 Screen wiper 3 0.5mm nickel-silver Etched, two-part
167 Horn 1 Ready made 5682/31
Metal wire Length for part Nos.
0.8 mm brass wire 1m 159
1.0 mm brass wire 0.33 m 155
1.2 mm brass wire 1 m 158,161
1.5 mm nickel-silver wire 3 m 62,63,67,78, 113,116, ,151,152,153,
Rubber rubbing strake (optional) 2 m Not included
