AIB-SO21/AIB-SO31/AIB-SN31/AIB-SN41 User Manual 14
7
GND
8
CSIA_D3P
9
CSIA_D3N
10
GND
11
CSIA_D2P
12
CSIA_D2N
13
GND
14
CSIA_CKP
15
CSIA_CKN
16
GND
17
CSIA_D1P
18
CSIA_D1N
19
GND
20
CSIA_D0P
21
CSIA_D0N
22
GND
◼ HDMI Type-A Connector
Item
Description
Location
CN7
Type
HDMI Type-A female connector
Pinout
Please refer to HDMI Type-A Standard
◼ M.2 M-Key Connector
Item
Description
Location
J3
Type
M.2 M-Key 2242
Pin
Please refer to M.2 M-Key Standard
