Aetina Jetson Platform AIB-SN31-1-A1 User Manual

AIB-SO21/AIB-SO31/AIB-SN31/AIB-SN41 User Manual 8
1.2 Specifications
◼ Carrier board specifications
Specification
AIB-SO21/31
AIB-SN31/41
Module Compatibility
Nvidia Jetson Orin Nano 4/8GB
Nvidia Jetson Orin NX 8/16GB
AI Performance
20/40 TOPS
70/100 TOPS
GPU
512 Core NVIDIA Ampere, with
16 Tensor Cores
1024 Core NVIDIA Ampere, with
32 Tensor Cores
1024 Core NVIDIA Ampere, with
32 Tensor Cores
CPU
6-core Arm
®
Cortex
®
-A78AE v8.2 64-bit
1.5MB L2 + 4MB L3
6-core Arm
®
Cortex
®
-A78AE v8.2 64-bit
1.5MB L2 + 4MB L3
8-core Arm
®
Cortex
®
-A78AE v8.2 64-bit
2MB L2 + 4MB L3
Memory
4GB 64-bit LPDDR5 34 GB/s
8GB 128-bit LPDDR5 68 GB/s
8GB 128-bit LPDDR5 102.4 GB/s
16GB 128-bit LPDDR5 102.4 GB/s
Storage
1 x M.2 M-Key 2242 (NVMe 128GB built-in)
Display
1 x HDMI 2.0 Type A
Audio
Line-out/Line-in/Mic (optional with daughter board)
Camera Input
2 x 4-Lane MIPI CSI-2 22-Pin Connector
LAN
1 x RJ-45 GbE Port
USB
2 x USB 3.2 Gen2 Type-A
1 x OTG Type-C
I/O Interfaces
5 x GPIO, 1 x I
2
C, 1 x I
2
S, 1 x RS-232, 1 x UART, 1 x UART (Debug Only),
1 x SPI, 1 x CAN
Expansion
1 x M.2 E-Key 2230 (Wifi/BT, PCIe x1
Gen3/USB 2.0)
1 x M.2 M-Key 2242 (NVMe 128GB
built-in, PCIe x4 Gen3)
1 x M.2 E-Key 2230 (Wifi/BT, PCIe x1
Gen3/USB 2.0)
1 x M.2 M-Key 2242 (NVMe 128GB
built-in, PCIe x4 Gen4)
MISC. Function
1 x Power/Recovery/Reset Button
1 x RS-232
1 x CAN 2.0b with isolation
Power Consumption
Idle: 5.5 W
Idle: 4.6 W
