AFA STAINLESS AFLZ01 - Parts List

5
3
11
10
4
6
7
8
9
10
1
2
1. 3-1/8" Supply Adapter
2. 4" Supply Adapter
3. Shower Arm
4. Shower Pipe
5. Adjustable Hand Shower Holder
6. Mounting Face Plate
7. Anchors
8. Screws
9. Bottom Mounting Bracket
10. Filter Gasket (Pre-installed)
11. Rain Shower Head
12. Hand Shower
13. Diverter Valve
SUPPLIES INCLUDED
T-1 Plumber’s Tape
T-2 1/2" Allen Wrench
T-3 3/32" Allen Wrench
T-4 Double Sided Tape ×2
PARTSLIST
5
13
12
