5. Mechanical Adjustments
#
Description
Where
How to Adjust
1
Seat Height
Seat pin under the battery
cover.
See attached assembling
drawing:
"Breeze S(4W) assembling.pdf"
Release both secure bolt and
level bolt. Change pin Level
hole as required . Resecure
bote level bolt and secure bolt.
Adjustments : 3 x 20 mm.
2
Tiller Height
Tiller bottom adaptor under
the rubber cover.
See attached assembling
drawing :
"Breeze S(4W) assembling.pdf"
Release the secure nut and
screw , adjust height and
resecure again the screw and
the nut.
Adjustments : 40 mm
continues.
3
Rear Shock
absorber Load
Rear Shock absorber under
the battery cover.
See attached assembling
drawing :
"Breeze S(4W) assembling.pdf"
I t is possible to replace the
whole shock absorber for
persons until 120 Kg and
above.
Also it is possible to adjust the
the load rate by changing the
Sprint pretention. 5 stages are
possible :
20% / 40% / 50% / 80% / 100%
Should be fit to user weights:
80 / 100 / 120 / 140 / 160 kg
Remark: The Adjust should fit
the comfort of the user .
