Afikim Breeze S - Internal LED Indicator Function; LCD Display Legend and Symbols; User Mode Dip Switch Configuration


d. Internal LED: Use for a technician. Can be seen only from the bottom
side of the LCD board. When LCD board active – flashes to indicate
OK.
e. Display Legend:
Signal Direction - Use to show Blinkers working.
Main Light - Use to show Front lights and rear Pilot lights are working.
Digital information - Shows : Speed ,Distance of Trip ,Time of Trip,
Time or Faults Codes.
Speed Units – Show mph(miles per hour) or kph (kilometers per hour).
Distance Units- Shows: mile (miles) or km (kilometers).
Time – Shows Hour = HH:mm (hours:minuts).
Half Speed – shows 1 (full) or 1/2 (half speed)
Battery Capacity – 8 Bars =full , 1 bar = empty, between is
proportional.
Also flashes at a CODE when there is a controller fault
CODE.
Warning / Inhibit - Indicate when the motor is heated , and when the
EMB is opened.
Dip Switches:
f. #1-2-5: User Modes setup with relate to user needs.
State
Description
"0" = On - On - On
Regular (Speed,Distance,Time ,Clock)
"1" = Off - On - On
Minimal (No Digital Information)
"2" = On - Off - On
Speed only
"3" = On - Off - Off
Speed and Distance only.
"4" = On - On - Off
Hour only.
