Afikim Breeze-S3 User Manual

25
5.2 LCD DISPLAY USE
Figure 7
(Numbers in the table refers to figure 6 & figure no. 7)
LCD Display
When driving and operating the Breeze, all the needed information is
displayed on the LCD screen (1.1).
See details below.
Battery Status
Indicator
The Battery Capacity Indicator (5.5) in the LCD screen, shows you the
remaining capacity of the batteries. Like in cars the Batteries indicator is not
absolute accurate, but will help you from running out of fuel. The best way to
use the battery indicator is to learn it's behavior to the change of the battery
capacity. When the indicator points 2-3 bars, recharge batteries as soon as
possible.
When the indicator left only last blink Bar , you should get to immediate
charging, it is possible to drive only a short distance (3-4 km on level
surface).The accuracy of the battery indicator reading depends also on the
type and age of the batteries.
Fault Indicator
The Breeze S is equipped with Fault indication.
The fault indication appears as a flashing code of the battery indicator and
as well as an Error Code at the LCD screen (5.5 & 5.12).
For further details see Breeze maintenance manual.
Light indicator
When the main lights are ON (front and rear) a sign will be lit (5.6).
