Remove batteries terminal insulating cap. Each time remove
only one cap. Unsecure the screw of the wiring terminal from
battery terminal using 10/13 mm key. Make sure your 10/13
mm key is not touching any other terminal or metal part. This
can cause damage and Injure.
After un securing all wires terminals, remove the batteries and
install the new ones. Connect the wires as shown in below
Figure 12. The connection Label is also located near the
batteries.
Secure all wires to the frame with Ties as shown in Figure 12.
Secure all terminals with screws and make sure insulating caps
are correctly placed on terminals.
Warning! Batteries contain high energy. Misconnection, short
circuits can burst with strong sparks causing heat and possible
fire.
Warning! Working with batteries can cause damage and Injure
if not done properly.
Note! Replacing batteries should be done only by trained and
or professional person.
