20
TROUBLESHOOTING AND FAULT REPAIR (Cont.)
No.
Symptom
Probable Causes
Remedy
6
SE does not move
when squeezing the
Operating Lever .
 Main Key Switch is in
OFF position.
 Charging Plug is
installed in
Charging Socket.
 The Mechanical Release
Lever of the
Electromagnetic Brake is
pushed Forward.
 Control system failure
 Turn the key to “ON”
position.
 Disconnect the Charging
Plug from the SE.
 Pull out the Lever
Backward
 Call for technical support.
7
Intermittent drive.
 Battery capacity low.
 Failed connections
 Faulty battery.
 Charge batteries for at
least 18 hours.
 Remove Gray Cover and
check the battery cables
connection. In case of
corrosion of the
terminals, clean the
terminals with a damp
clean cloth.
 If, after recharge, the red
lamps are still ON, the
battery may be faulty. For
replacement, contact
your dealer.
8
RIGHT or LEFT turn
signal light is
inoperative.
 Blown light fuse or
popped out - Figure 1.
 Burnt out bulb.
 Replace light fuse or
reset fuse if automatic -
see Figure 1.
 Replace bulb.
9
Headlight and/or rear
light are not lit.
 Blown light fuse or
popped out - Figure 1.
 Burnt out bulb.
 Replace light fuse or
reset fuse if automatic -
see Figure 1.
 Replace Headlight bulb.
